The unit is fitted with a double 20” x 4.5” housing system comprising of a 5mic sediment filter and a 10mic carbon block. These filters are designed to protect the pump and membrane only and are not installed as a system pre-treatment. Changing the cartridges regularly will help prevent excessive blockage that could be detrimental to the system.
| Performance | @ 25°C, 2000ppm TDS* |
| Feed flow | 2.1 m³/hr |
| Permeate flow | 0.3 m³/hr |
| Recovery | Up to 50% |
| Rejection | 95 - 98% |
| Operating pressure | 200 psi max |
| Inlet pressure | 40 - 90 psi max |
| Temperature | 45°C max |
| Membrane housing | 3 x 4040 Fibreglass |
| Membrane | 3 x RE-4040-BE CSM |
| Pre-filtration | 20” x 4.5” |
| 1 x 5 µm Sediment | |
| 1 x 10 µm Carbon | |
| Pump & Motor | Grundfos |
| CR1-23 X-P-A-E HQQE | |
| 1.1 kw 240V 50 hz | |
| Piping | High pressure reinforced |
| Electrical | 1.65 m power cord with 15A plug |
| Controller | ROC 2315 Microprocessor |
| Frame | Stainless Steel |
| Connections | 1” Inlet, 1” M Concentrate, |
| 1” M Permeate & 1/2” M Comp | |
| Brine | |
| Dimensions | 1420 H x 770 W x 790 D |
